| P
|
螺距 |
| a
|
最大值 |
| dk
|
最大值=公称 |
| 最小值 |
| k
|
最大值=公称 |
| 最小值 |
| r
|
最小值 |
| R
|
≈ |
| x
|
最大值 |
| 槽号
|
|
| m
|
≈ |
| 深度
|
最大值 |
| 最小值 |
|
| 0.4 |
0.45 |
0.5 |
0.6 |
0.7 |
0.8 |
1 |
1.25 |
| 0.8 |
0.9 |
1 |
1.2 |
1.4 |
1.6 |
2 |
2.5 |
| 3.5 |
4.5 |
5.5 |
6.0 |
7.0 |
9.0 |
10.5 |
14.0 |
| 3.2 |
4.2 |
5.2 |
5.7 |
6.64 |
8.64 |
10.07 |
13.57 |
| 1.4 |
1.8 |
2.15 |
2.45 |
2.75 |
3.45 |
4.1 |
5.4 |
| 1.26 |
1.66 |
2.01 |
2.31 |
2.61 |
3.27 |
3.8 |
5.1 |
| 0.1 |
0.1 |
0.1 |
0.1 |
0.2 |
0.2 |
0.25 |
0.4 |
| 4.5 |
6 |
7 |
8 |
9 |
12 |
14 |
18 |
| 1 |
1.1 |
1.25 |
1.5 |
1.75 |
2 |
2.5 |
3.2 |
| 1 |
1 |
2 |
2 |
2 |
2 |
3 |
3 |
| 2.2 |
2.6 |
3.5 |
3.8 |
4.1 |
4.8 |
6.2 |
7.7 |
| 1.01 |
1.42 |
1.43 |
1.73 |
2.03 |
2.73 |
2.86 |
4.36 |
| 0.6 |
1 |
0.86 |
1.15 |
1.45 |
2.14 |
2.26 |
3.73 |
|
